MagiClick S3 based on circuitpython

a keyboard, esp32-s3

Similar projects worth following
  • Description
  • Details
  • Files 0
  • Components 0
  • Logs 0
  • Instructions 0
  • Discussion 0
A single-button keyboard, based on ESP32-S3, with a color screen.

CircuitPython is used by default. You can also use MicroPython, Arduino.

The display part adopts a 0.85-inch color screen, 128x128 resolution, and the display content is delicate
The main control board is currently only designed with the esp32s3 version, which supports WiFi, flash and RAM large enough to help add more functional scripts
The overall operation is mainly based on the mechanical axis buttons in the middle, and the left and right sides of the fuselage are generally used as auxiliaries
The keyboard axis uses a pluggable design, and you can freely choose the silent axis or others
Built-in a small speaker, listening to a sound is so easy
An on-board 6-axis motion sensor
There is an expansion port on the rear side of the fuselage
USB Type-C interface
One reset button at the bottom
On-board colorful LEDs
